On-Stage DB200 Mini DI Box
On-Stage DB200 Mini DI Box Overview:
Our DB200 Mini DI Box converts any high-impedance 1/4" source to a low-impedance XLR signal ready to send via a long cable run to a mixer or PA system. A cab simulator switch enables sending the input signal through an emulated amp directly to a mixer without using a physical amp. There's a switch for either +20 dB of gain to boost weak signals or a -20 dB pad to prevent clipping from louder sources. A ground-lift switch defeats ground-loop hum. When not using the DI\n the true-bypass switch eliminates the circuitry of the pedal from the signal path. Balanced and unbalanced outputs provide the option to send the signal to an amp\n a mixer\n or both. This pedal includes hook-and-loop strips for convenient pedalboard mounting. Its heavy-duty metal enclosure protects the internal components and ensures reliable performance.
\n\n
Features
\n- \n
- Accepts a wide range of audio sources including guitars\n basses\n and keyboards \n
- Compact footprint saves space on pedal boards (includes hook-and-loop mounting strips) \n
- Cab simulator sends the input signal through an emulated amp to a mixer or PA system \n
- Gain/pad switch boosts weak signals or prevents clipping \n
\n
Specifications
\n- \n
- Input Impedance: 1M Ohms \n
- Output Impedance: 1k Ohms \n
- Current Draw: 12mA \n
- Power Supply: 9V DC\n center negative (not included) \n
- Dimensions: 3.6" x 1.5" x 1.3"
- Color: Black
Original: $4,405.00
-70%$4,405.00
$1,321.50More Images
On-Stage DB200 Mini DI Box
On-Stage DB200 Mini DI Box Overview:
Our DB200 Mini DI Box converts any high-impedance 1/4" source to a low-impedance XLR signal ready to send via a long cable run to a mixer or PA system. A cab simulator switch enables sending the input signal through an emulated amp directly to a mixer without using a physical amp. There's a switch for either +20 dB of gain to boost weak signals or a -20 dB pad to prevent clipping from louder sources. A ground-lift switch defeats ground-loop hum. When not using the DI\n the true-bypass switch eliminates the circuitry of the pedal from the signal path. Balanced and unbalanced outputs provide the option to send the signal to an amp\n a mixer\n or both. This pedal includes hook-and-loop strips for convenient pedalboard mounting. Its heavy-duty metal enclosure protects the internal components and ensures reliable performance.
\n\n
Features
\n- \n
- Accepts a wide range of audio sources including guitars\n basses\n and keyboards \n
- Compact footprint saves space on pedal boards (includes hook-and-loop mounting strips) \n
- Cab simulator sends the input signal through an emulated amp to a mixer or PA system \n
- Gain/pad switch boosts weak signals or prevents clipping \n
\n
Specifications
\n- \n
- Input Impedance: 1M Ohms \n
- Output Impedance: 1k Ohms \n
- Current Draw: 12mA \n
- Power Supply: 9V DC\n center negative (not included) \n
- Dimensions: 3.6" x 1.5" x 1.3"
- Color: Black
