Sonodyne SM 300 3 way Trimaplified Monitor Speaker

Sonodyne SM 300 3 way Trimaplified Monitor Speaker Overview:

The SM 300 is acompact 3 way monitor. Capable of playing loud, and clear, and with excellent detail, the SM 300 is an ideal reference monitor. A tri-amplified speaker with internal DSP balance, the SM 300 has exceptional on and off axis response. The 8 " kevlar LF transducer ensures that the lowest notes and upper mid transients are produced with detail and clarity. With the SM 300, your need for a single monitor for high quality recording and post in are adequately met.

HIGHLIGHTS

• 3 way trimaplified speaker
• Aluminium - MDF hybrid rigid enclosure
• Kevlar woofer and midrage
• Custom waveguide for HF
• 3 EQs
• High in details and dynamics

SPECIFICATIONS

• DESCRIPTION: 3 way active studio monitor
• ENCLOSURE Sides: Extruded aluminium, Top/bottom/front/rear: MDF, vented
• TRANSDUCER COMPLEMENTS: HF Magnetically shielded 25mm silk dome tweeter
• TRANSDUCER COMPLEMENTS: MF Magnetically shielded 4" kevlar cone midrange
• TRANSDUCER COMPLEMENTS: LF Magnetically shielded 8" kevlar cone woofer
• AMPLIFIER POWER BEFORE CLIPPING LF: 150 W, MF: 75 W, HF: 75 W
• AMPLIFIER THD AT RATED POWER: < 0.1%
• MAX SPL @ 1M: 116 dB
• OVERALL FREQUENCY RESPONSE (+/-2 DB): 40 Hz ~ 22 kHz
• USABLE FREQUENCY RANGE (-10 DB): 35 Hz ~ 27 kHz (-10 dB)
• CROSSOVER FREQUENCY: 400 Hz, 4 kHz
• CMRR: > 70 dB
• INPUTS: Fully balanced XLR socket with link
• INPUT LEVEL FOR 90 DB SPL @ 1M: +6 dBu, with gain at mid position
• CONTROLS Front: 2 bass roll-off DIP switches - 80 Hz & 100 Hz
• PROTECTION: Overcurrent, overheat, RFI, switch-on/off transients
• INDICATOR: Power ON /OFF
• GAIN CONTROL RANGE: -20 dB ~ +8 dB
• HIGH SHELVING: EQ 4 kHz ~ 20 kHz, -3 dB to +3 dB in 0.75 dB steps
• LOW SHELVING: EQ 50 Hz ~ 250 Hz, -3 dB to +3 dB in 0.75 dB step
• BASS ROLL-OFF: 2 bass roll-off DIP switches: 80 Hz and 100 Hz
• SIGNAL TO NOISE RATIO (AT UNITY GAIN): > 95 dB, referred to full output
• FINISH: Black painted
• COLOURS: Black
• DIMENSIONS (HXWXD): MM 300 x 508 x 295
• POWER CONSUMPTION: 480 VA max
• POWER REQUIREMENT: Two versions: 230 V AC and 120 V AC, +/- 10%
• NET WEIGHT: 25 kg
• MOUNTING OPTIONS: 4 x M6 inserts on bottom plate

Made in India
