Sonodyne SM 3300 3 way Active Studio Monitor

Sonodyne SM 3300 3 way Active Studio Monitor Overview:

The SM 3300 is a main monitor. Capable of playing loud, and clear and delivering the lowest LF notes, the SM 3300 will fill your studio with body and detail . A tri-amplified speaker, the HF and Mids are nested in a rotatable waveguide, that, assisted by internal DSP balance, results in exceptional on and off axis response. A new 12" LF transducer ensures that the lowest notes and upper mid transients are produced with detail and clarity. With the SM 3300, experience unheard detail and power in main monitors!

HIGHLIGHTS

• 3 way triamplified main monitor
• Aluminum - MDF hybrid rigid enclosure
• Kevlar midrange
• Custom waveguide for HF
• 3 EQs

SPECIFICATIONS

• DESCRIPTION: 3 way active studio monitor
• ENCLOSURE: Vented, through front-firing aerodynamic port; MDF, with extruded aluminium corners
• TRANSDUCER COMPLEMENTS: HF Magnetically shielded 26mm silk dome tweeter with waveguide
• TRANSDUCER COMPLEMENTS: MF Magnetically shielded 5 " Kevlar cone midrange
• TRANSDUCER COMPLEMENTS: LF 12" coated cone woofer
• AMPLIFIER CLASS: Class AB
• AMPLIFIER POWER BEFORE CLIPPING: LF: 300 W, MF: 75 W,HF: 75 W
• AMPLIFIER THD AT RATED POWER: < 0.04 %
• MAX SPL @ 1M: 122 dB
• OVERALL FREQUENCY RESPONSE (+/-2 DB): 30 Hz ~ 22 kHz
• USABLE FREQUENCY RANGE (-10 DB): 25 Hz ~ 25 kHz
• CROSSOVER FREQUENCY: 350 Hz, 3 kHz
• CMRR: > 65 dB, 1 kHz
• INPUTS: Fully balanced XLR socket
• INPUT LEVEL FOR 90 DB SPL @ 1M: +7 dBU
• INPUT IMPEDANCE: 22 kOhms
• OUTPUTS: Link: Fully balanced XLR
• CONTROLS - REAR: Power switch, Gain control, Low shelving, High shelving, Bass roll-off, Mid EQ
• PROTECTION: Over current, Overheat , RFI, Switch on/ off transients
• GAIN CONTROL RANGE: -∞ to +6dB, 0dB at center position
• HIGH SHELVING EQ: 4 kHz ~ 20 kHz, -3 dB to +3 dB in 0.75 dB steps
• LOW SHELVING EQ: 50 Hz ~ 250 Hz, -3 dB to +3 dB in 0.75 dB step
• BASS ROLL-OFF: 63 Hz, 12 dB/ octave
• SIGNAL TO NOISE RATIO (AT UNITY GAIN): > 90 dB, referred to full output
• FINISH: Black painted
• COLOURS: Black
• DIMENSIONS (HXWXD): MM 750 x 398 x 450
• POWER CONSUMPTION: 625 W max
• POWER REQUIREMENT: Two versions: 230 V AC and 120 V AC, +/- 10%
• NET WEIGHT: 45 k

Made in India
